Double insulated DEWALT 65 mm fan cooled motor with replaceable brushes for maximum power in hard wood

New mitre angle adjustment system provides accurate and consistent setting of mitre angles between 0 and 48° right and 0 and 48° left

The dual fence mechanism gives maximum support in large material cuts at any angle or combination of angles

Horizontal rails create additional capacity for larger materials

The aluminium base construction provides stability to the saw while still retaining its portability

Mitre and bevel angle detents for quick and easy set up of the saw

Power Output 590 Watt
Voltage 18 V
Blade Speed 3750 rpm
Blade Diameter 184 mm
Blade Bore 16 mm
Bevel Capacity 48°
Mitre Capacity [right/left] 48/48°
Cutting Capacity at 90°/90° (W x H) 250 x 50 mm
Cutting Capacity at 45°/90° (W x H) 176 x 50 mm
Cutting Capacity at 90°/45° (W x H) 250 x 35 mm
Max. Cutting Capacity at 45°/45° 176x35 mm
Weight 11.5 kg
Depth 590 mm
Length 490 mm
Height 590 mm

No batteries or charger supplied
