This contemporary chrome finish bar diverter mixer shower features a push button to make switching between the single spray pattern shower handset and fixed (rainfall) shower head easy whilst showering. It includes thermostatic temperature control and a stylish shelf.

Brand Name	Triton
Colour	Chrome
Material	Chrome
Manufacturer Model No	PBDIVCHR
Wear Type	N/A
Type	Mixer Shower
Certifications Met	N/A
Country of Origin	N/A
Protects From	N/A
Waterproof	N/A
Number of Pockets	N/A
Guarantee	5 Years
Plumbing System	Suitable for high pressure systems only
Inlet Connections	15mm push-fit (fixings to pipe) 3/4� flat face union (valve to fixings)
Minimum Running Pressure / Flow	0.5 Bar @ 8 l/min
Maximum Running Pressure	5 Bar
Temperature Control	Yes
Adjustable Maximum Temperature Stop	Yes
Automatic Shutdown	Yes
Separate Flow and Temperature Controls	Yes
Number of Spray Patterns (Showerhead 1)	1 (handset)
Number of Spray Patterns (Showerhead 2)	1 (fixed head)
Shower Head Diameter	130mm x 50mm (handheld); 255mm x 190mm (fixed head)
Rail Diameter	22mm
Rail Length	Approx 1120mm
Hose Length	1.25m
Hose Material	Double interlocked stainless steel

Brand Name	Triton
Colour	Chrome
Material	N/A
Manufacturer Model No	PBDIVCHR
Wear Type	N/A
Type	Mixer Shower
Certifications Met	N/A
Country of Origin	N/A
Protects From	N/A
Waterproof	N/A
Number of Pockets	N/A
Shower Type	Bar Mixer
Outlets	Twin Outlet
Style	Contemporary
Head Type	Multiple
Supply Type	HP / Combi
Low Pressure Suitable	No
Combi Boiler Suitable	Yes
High Pressure Suitable	Yes
Mobile App Connectivity	No
Amazon Alexa Connectivity	No
Google Home Connectivity	No
Spray Patterns	1
Shower Head Width	255 mm
Water Feed	Rear Wall Fed
Temperature Control	Thermostatic
Range	Push Button
Installation Type	Exposed

Perfect for either a shower enclosure or over the bath. Offers contemporary style and great performance. The easy-click push-button makes it simple to choose between the drench head shower or the shower handset providing flexible showering for all the family.

Brand Name	Triton
Colour	Chrome
Material	None
Manufacturer Model No	685JJ
Wear Type	None
Type	Mixer Shower
Certifications Met	None
Country of Origin	None
Protects From	None
Waterproof	None
Number of Pockets	None
Suitable for High Pressure Water Systems Only	Yes
Delivers	5Ltr/min at 1.0bar
Mixer Type	Thermostatic
Fixed Head & Riser Rail	Yes
Single-Spray Pattern Shower Head	Yes

Brand Name	Triton
Colour	Chrome
Material	Brass & stainless steel
Guarantee	5 years
Comes with	Fixtures and Fittings Included
Compatible with	Retro fit to a bar mixer
Handle type	Push button
Hose length	1.5m
Maximum operating pressure	3bar
Minimum operating pressure	1bar
Mixer type	Thermostatic
Model name/number	Push Button Mixer Chrome
Number of shower heads	2
Shower type	Mixer
Product depth	104mm
Product height	1120mm
Product width	304mm
Product code	5012663155619

Brand Name	Triton
Colour	Chrome
Material	N/A
Manufacturer Model No	PBDIVCHR
Wear Type	N/A
Type	Mixer Shower
Certifications Met	WRAS Approved
Country of Origin	N/A
Protects From	N/A
Waterproof	N/A
Number of Pockets	N/A
Temperature Control	Thermostatic
Suitable for	N/A
Style	N/A
Standards Met	N/A
Range	Push Button
Power Type	Mixer
Pipe Entry	N/A
Pipe Connector Size	N/A
Outlet size	N/A
Outlet Connection	1/2" BSP Bottom
Number of Modes	N/A
Model	Push Button
Minimum Static Pressure	N/A
Maximum Static Pressure	10 bar
Maximum Operating Pressure	N/A
Inlet Size	N/A
Inlet Connections	15mm push-fit (fixings to pipe) 3/4” flat face union (valve to fixings)
Includes	N/A
IP Rating	N/A
Hose Length	1.25mm
Flow Rate	Hand held 8.0l/min Overhead 8.0l/min
Finish	N/A
ERP Rating	A
Compatible With	No
Cable Entry	N/A
Supplier Part Number	PBDIVCHR
Range Description	This contemporary bar diverter mixer shower features a push button to make switching between the single spray pattern shower handset and fixed (rainfall) shower head easy whilst showering. Further functionality comes in the form of thermostatic temperature control, ensuring the shower holds a constant temperature for safe family showering.
