The Stelrad Compact Vertical Line Vertical Concept K2 Type 22 Anthracite Radiator is a high-quality heating solution designed for efficiency and style. Emphasising clean and sleek design lines that complement contemporary interiors, its vertical orientation not only maximises heat distribution but also fits seamlessly into narrow spaces, optimising wall usage. The smooth, uninterrupted lines create a minimalist aesthetic, making it a stylish addition to any room. This design approach ensures efficient heating while adding a modern touch to your space.

Brand Name	Stelrad
Colour	Anthracite
Material	Steel
Manufacturer Model No	18182204
Type	K2 Type 22
Certifications Met	EN442, CE
Country of Origin	N/A
Height	1800mm
Width	400mm
Watts DT50	1476
BTU DT50	5036
Maximum Pressure	10 bar
Installation Type	Hot water centeral heating
Inlet Conection	1/2"

Brand Name	Stelrad
Colour	Grey
Manufacturer Model No	101HX
BTU	5036 BTU
BTU Band	4001-6000
CALC - No. of Panels	Double Panel
Connection Size	1/2 "
Delta T	Delta T50°C
Finish Code	Finished to RAL 7024
Manufacturer Guarantee	10 Year Manufacturer's Guarantee (T&Cs Apply)
Max. Working Pressure	10 bar
Max. Working Temperature	95 °C
Model Name	Accord Concept
Mounting Orientation	Vertically-Mounted
No. of Panels	Double Flat Panel
Orientation	Vertical
Pack Size	1
Parent Colour	Grey
Pieces in Pack/Case	1
Power Output (Watts/Kw)	1476 W
Product Height	1800 mm
Product Type	Radiator
Product Width	400 mm
Projection from Wall (Std Bracket)	129 mm
Radiator Accessories Included	Brackets, Plug & Vent Included
Radiator Coating & Finish	Powder-Coated
Radiator Colour	Grey
Radiator Height Band	1800mm or Greater
Radiator Product Type	Convector
Radiator Type Number	Type 22
Radiator Water Content	6.36 Ltr
Radiator Width Band	301-500mm
Shape Orientation	Radiator is taller than it is wide
Smart Compatibility	Not Smart
Suitable System	Suitable for Domestic & Commercial Use
Test Pressure	13 bar
Total Product Weight	42.1 kg
Wall to Centre (Standard Bracket)	73 mm
